BRAND : InBody
BWA2.0S is the world’s first BIA device to use 3MHz to improve the accuracy of the measurement and it also enabled to accurately measure severe edema patients. Not only did this increase the accuracy but it also provided a way to add parameters such as Multi-reactance(5kHz, 50kHz, 250kHz), Multi-phase angle(5kHz, 50kHz, 250kHz), and Segmental Phase-Angle
The BWA2.0S clamp electrode is made up of two forceps that can measure the impedance of the center and the distal part respectively. The difference between the two impedances can be used as clinical indicators for wrist and ankle swelling. The clamp electrode also has an indicator function that can be attached between the wrist and ankle bones, which provides high reproducibility.
Specifications
-
- Height Range
- 95 – 220 cm (3 ft 1.4 in – 7 ft 2.6 in)
- Equipment Weight
- 2.8 kg (6.17 lb, BWA2.0 only)
- Dimensions
- 322 (W) × 282 (L) × 81.5 (H): mm
12.7 (W) × 11.1 (L) × 3.2 (H): inch
- Database
- Saves up to 100,000 measurements (When ID is entered)
- Frequencies
- 5 kHz, 50 kHz, 250 kHz, 500 kHz, 1 MHz, 3 MHz
- Test Duration
- About 30 seconds for Medical Mode, about 60 seconds for Research Mode
-
- Weight Range
- 2 – 250 kg (4.4 – 551.2 lb)
- Age Range
- 3+ years
- Accessories
- Stadiometer, Blood pressure monitor, Thermal Printer (TP100), Serial Distributor (SD400), InGrip, BWA2.0 Portable Case, BWA2.0 Adhesive Electrodes and Tape and BWA2.0 Battery Pack from InBody, USB Thumb Drive
- Warranty
- 2 Year Manufacturer’s Warranty
- Compatible Printers
- Laser/Inkjet PCL 3 or above and SPL
- Measurements
- 30 Impedance Measurements by Using 6 Different Frequencies (5 kHz, 50 kHz, 250 kHz, 500 kHz, 1 MHz, 3 MHz) at Each of 5 Segments (Right Arm, Left Arm, Trunk, Right Leg and Left Leg)
-
- Additional Features
- LookinBody 120 and LookinBody Web Compatible, Touchscreen, Voice Guidance System, InBodyBAND Series Recognition Function, Fingerprint Recognition Function, WiFi/Bluetooth Connectivity, Security Access Code
- Standard Outputs
- weight, total body water, lean mass, skeletal muscle mass, body fat percentage, partial muscle mass, extracellular water, partial ECW analysis, whole body phase angle
- Additional Outputs
- InBody score, basal metabolic rate, visceral fat area, weight control, impedance graph
